| Product Name | DC Spark-over Voltage @100V/S | Maximum Impulse Spark-over Voltage @100V/μS | Maximum Impulse Spark-over Voltage @1KV/μS | Minimum Insulation Resistance | Maximum Capacitance @1MHz | Arc Voltage @1A | Nominal Impulse Discharge Current @8/20μs ±5times | Package | Data Sheet |
|---|---|---|---|---|---|---|---|---|---|
SC1812-600CSMD
|
600V±20% | 1100V | 1200V | 1 GΩ (at 100V DC) | 1.0pF | 15V | 2KA | 1812 |
|
|
SC1812-350CSMD
|
350V±20% | 800V | 900V | 1 GΩ (at 100V DC) | 1.0pF | 15V | 2KA | 1812 |
|
|
SC1812-470CSMD
|
470V±20% | 900V | 1000V | 1 GΩ (at 100V DC) | 1.0pF | 15V | 2KA | 1812 |
|
|
SC1812-420CSMD
|
420V±20% | 900V | 1000V | 1 GΩ (at 100V DC) | 1.0pF | 15V | 2KA | 1812 |
|
|
SC1812-300CSMD
|
300V±20% | 800V | 900V | 1 GΩ (at 100V DC) | 1.0pF | 15V | 2KA | 1812 |
|
|
SC1812-230CSMD
|
230V±20% | 600V | 750V | 1 GΩ (at 100V DC) | 1.0pF | 15V | 2KA | 1812 |
|
|
SC1812-200CSMD
|
200V±20% | 600V | 750V | 1 GΩ (at 100V DC) | 1.0pF | 15V | 2KA | 1812 |
|
|
SC1812-150CSMD
|
150V±20% | 600V | 700V | 1 GΩ (at 50V DC) | 1.0pF | 15V | 2KA | 1812 |
|
|
SC1812-90CSMD
|
90V±20% | 600V | 700V | 1 GΩ (at 50V DC) | 1.0pF | 15V | 2KA | 1812 |
|
|
SC1812-400CSMD+
|
420V±20% | 900V | 1000V | 1 GΩ (at 100V DC) | 1.0pF | 15V | 2KA | 1812 |
|
|
SC1812-400CSMD
|
400V±20% | 900V | 1000V | 1 GΩ (at 100V DC) | 1.0pF | 15V | 2KA | 1812 |
|
