| Product Name | Vr (V) | Vbr (V) (Min.) | Vbr (V) (Typ.) | Vbr (V) (Max.) | Vc (V) @1A | Vc (V) @ Ipp Max. | Ipp (A) | Ir (μA) | Cj (pF) Min. | Cj (pF) Typ. | Cj (pF) Max. | Package | Data Sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SE03N2C01HZ
|
3.3 | 4.1 | -- | 7.0 | 9.0 | 19.0 | 3.0 | 1.0 | -- | 0.4 | -- | DFN0603-2L |
|
|
SE03N2S01GZ
|
3.3 | 3.6 | 4.1 | 5.0 | -- | 8 | 10 | 1.0 | -- | 13.0 | -- | DFN0603-2L |
|
|
SE05N2C01HZ
|
5.0 | 5.6 | -- | 9.0 | 9.5 | 13.5 | 4 | 1.0 | -- | 0.4 | -- | DFN0603-2L |
|
|
SE05N2S01HZ_
|
5.0 | 5.6 | -- | 8.0 | 9.8 | 13 | 6 | 0.1 | -- | 12.0 | 15.0 | DFN0603-2L |
|
