| Product Name | Resistance (25℃) (kΩ) | B Constant (25/50℃) (K) | B Constant (25/85℃) (K) | Permissible Operating Current (25℃) (mA) | Dissipation Factor (mW/℃) | Thermal Time Constant (s) | Rated Electric Power (25℃) (mW) | Operating Ambient Temperature (℃) | Package | Data Sheet |
|---|---|---|---|---|---|---|---|---|---|---|
SN0402X103F3435FA
|
10±1% | - | 3435±1% | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X103F3450FB
|
10±1% | 3450±1% | -- | -- | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X103F3950FB
|
10±1% | 3950±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X223F3950FB
|
22±1% | 3950±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X333F4050FB
|
33±1% | 4050±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X473F4050FB
|
47±1% | 4050±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X683F4150FB
|
68±1% | 4150±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X104F3950FB
|
100±1% | 3950±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X104F4250FB
|
100±1% | 4250±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X104F4310FA
|
100±1% | - | 4310±1% | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X474F4050FA
|
470±1% | -- | 4050±1% | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X103H3380FB
|
10±3% | 3380±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X103H3435FA
|
10±3% | -- | 3435±1% | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X103H3450FB
|
10±3% | 3450±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X103H3950FB
|
10±3% | 3950±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X223H3950FB
|
22±3% | 3950±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X333H4050FB
|
33±3% | 4050±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X473H4050FB
|
47±3% | 4050±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X683H4150FB
|
68±3% | 4150±1% | -- | -- | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X104H3950FB
|
100±3% | 3950±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X104H4250FB
|
100±3% | 4250±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X104H4310FA
|
100±3% | -- | 4310±1% | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X474H4050FA
|
470±3% | -- | 4050±1% | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X103J3380FB
|
10±5% | 3380±1% | -- | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X103J3435FA
|
10±5% | -- | 3435±1% | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X103J3450FB
|
10±5% | 3450±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X103J3950FB
|
10±5% | 3950±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X223J3950FB
|
22±5% | 3950±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X333J4050FB
|
33±5% | 4050±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X473J4050FB
|
47±5% | 4050±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X683J4150FB
|
68±5% | 4150±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X104J3950FB
|
100±5% | 3950±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X104J4250FB
|
100±5% | 4250±1% | - | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X104J4310FA
|
100±5% | -- | 4310±1% | -- | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
|
SN0402X474J4050FA
|
470±5% | -- | 4050±1% | - | 1.0 | 3.0 | 100 | -40 ~ +125 | 0402 |
|
