| Product Name | VAC(V) | VDC(V) | V1mA(V) | Ip(A) | Vc(V) | I(A) Standard 1 Time |
I(A) Standard High Surge1 Time |
Cp@1KHZ（pf） | Package | Data Sheet |
|---|---|---|---|---|---|---|---|---|---|---|
25D201K/25D201KJ
|
130 | 170 | 200(185-225) | 150 | 330 | 15000 | 20000 | 2000 | 25D |
|
|
25D221K/25D221KJ
|
140 | 180 | 220(198-242) | 150 | 360 | 15000 | 20000 | 1800 | 25D |
|
|
25D241K/25D241KJ
|
150 | 200 | 240(216-264) | 150 | 395 | 15000 | 20000 | 1650 | 25D |
|
|
25D271K/25D271KJ
|
175 | 225 | 270(243-297) | 150 | 455 | 15000 | 20000 | 1500 | 25D |
|
|
25D301K/25D301KJ
|
190 | 250 | 300(270-330) | 150 | 505 | 15000 | 20000 | 1300 | 25D |
|
|
25D331K/25D331KJ
|
210 | 275 | 330(297-363) | 150 | 550 | 15000 | 20000 | 1200 | 25D |
|
|
25D361K/25D361KJ
|
230 | 300 | 360(324-396) | 150 | 595 | 15000 | 20000 | 1100 | 25D |
|
|
25D391K/25D391KJ
|
250 | 320 | 390(351-429) | 150 | 650 | 15000 | 20000 | 1000 | 25D |
|
|
25D431K/25D431KJ
|
275 | 350 | 430(387-473) | 150 | 710 | 15000 | 20000 | 930 | 25D |
|
|
25D471K/25D471KJ
|
300 | 385 | 470(423-517) | 150 | 775 | 15000 | 20000 | 850 | 25D |
|
|
25D511K/25D511KJ
|
320 | 415 | 510(459-561) | 150 | 845 | 15000 | 20000 | 780 | 25D |
|
|
25D561K/25D561KJ
|
350 | 460 | 560(504-616) | 150 | 920 | 15000 | 20000 | 715 | 25D |
|
|
25D621K/25D621KJ
|
385 | 505 | 620(558-682) | 150 | 1025 | 15000 | 20000 | 650 | 25D |
|
|
25D681K/25D681KJ
|
510 | 670 | 820(738-902) | 150 | 1355 | 15000 | 20000 | 500 | 25D |
|
|
25D911K/25D911KJ
|
550 | 745 | 910(819-1001) | 150 | 1500 | 15000 | 20000 | 440 | 25D |
|
|
25D102K/25D102KJ
|
625 | 825 | 1000(900-1100) | 150 | 1650 | 15000 | 20000 | 650 | 25D |
|
|
25D112K/25D112KJ
|
680 | 895 | 1100(990-1210) | 150 | 1815 | 15000 | 20000 | 600 | 25D |
|
|
25D122K/25D122KJ
|
750 | 990 | 1200(1080-1320) | 150 | 1980 | 15000 | 20000 | 550 | 25D |
|
|
25D201K/25D201KJ
|
130 | 170 | 200(185-225) | 150 | 330 | 15000 | 20000 | 2000 | 25D |
|
|
25D201K/25D201KJ
|
130 | 170 | 200(185-225) | 150 | 330 | 15000 | 20000 | 2000 | 25D |
|
|
25D201K/25D201KJ
|
130 | 170 | 200(185-225) | 150 | 330 | 15000 | 20000 | 2000 | 25D |
|
