| Product Name | Vr (V) | Vbr (V) (Min.) | Vbr (V) (Typ.) | Vbr (V) (Max.) | Vc (V) @1A | Vc (V) @ Ipp Max. | Ipp (A) | Ir (μA) | Cj (pF) Min. | Cj (pF) Typ. | Cj (pF) Max. | Package | Data Sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SE03N6L01GZ
|
3.3 | 5.0 | -- | 6.5 | 11.0 | 27.0 | 5.0 | 1.0 | -- | 0.4 | -- | DFN1006-2L |
|
|
SE18N6C01HJ
|
18.0 | 18.2 | 18.5 | -- | 6.0 | 10.0 | 4.0 | 0.1 | -- | 0.55 | -- | DFN1006-2L |
|
|
SE05N6C01GK
|
5.0 | 6.5 | 7.5 | 9.0 | 11.0 | 20.0(typ.) | 5.0 | 1.0 | -- | 0.35 | -- | DFN1006-2L |
|
|
SE07N6S41GZ
|
7.0 | 7.6 | -- | 9.0 | 12.0 | 16.0 | 6.5 | 0.1 | -- | 15.0 | 20.0 | DFN1006-2L |
|
|
SE05N6R01GU
|
5.0 | 5.6 | 6.5 | 8.4 | 8.5 | 9.5(typ.) | 5.0 | 1.0 | -- | 9.0 | -- | DFN1006-2L |
|
|
SE03N6S01GZ
|
3.3 | 3.5 | 4.1 | 5.0 | 6.0 | 10.0 | 8.0 | 0.5 | -- | 12 | -- | DFN1006-2L |
|
|
SE12N6R01GK
|
12.0 | 13.3 | -- | 16.0 | 19.0 | 22.0 | 3.5 | 1 | -- | 6.0 | -- | DFN1006-2L |
|
|
SE15N6T01GK
|
15.0 | 17 | -- | 19.5 | 22 | 31(typ.) | 8.0 | 0.1 | -- | 20 | -- | DFN1006-2L |
|
