| Product Name | Ihold(A) | Itrip(A) | Vmax(Vdc) | Imax(A) | Pdtyp.(W) | Maximum Time To TripCurrent (A) | Maximum Time To TripTime (Sec.) | Rmin(Ω) | Rmax(Ω) | R1max(Ω) | Data Sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
SC16-200SW0D
|
2.00 | 4.00 | 16 | 40 | 1.0 | 10.0 | 8.0 | 0.030 | -- | 0.075 |
|
|
SC16-1000SZ0A
|
10.0 | 17.0 | 16 | 100 | 3.6 | 30 | 15 | 4.0 | 10.0 | 12.5 |
|
SC16-600SZ1D
|
6.00 | 12.00 | 16 | 40 | 2.80 | 30.0 | 5.8 | 0.010 | 0.015 | 0.035 |
|
SC16-120CW0D
|
1.20 | 2.40 | 16 | 40 | 0.60 | 6.00 | 5.5 | 0.070 | -- | 0.240 |
|
|
SC16-065CW0A
|
0.65 | 1.30 | 16 | 40 | 0.50 | 1.95 | 10 | 0.12 | 0.27 | 0.40 |
|
|
SC16-075CW0A
|
0.75 | 1.50 | 16 | 40 | 0.55 | 2.25 | 10 | 0.11 | 0.25 | 0.345 |
|
|
SC16-075CW0D
|
0.75 | 1.50 | 16 | 40 | 0.30 | 3.75 | 4.8 | 0.11 | 0.17 | 0.28 |
|
|
SC16-090SW0A
|
0.50 | 1.0 | 16 | 40 | 0.45 | 1.5 | 10 | 0.2 | 0.45 | 0.675 |
|
|
SC16-090SW0D
|
0.90 | 1.8 | 16 | 40 | 0.6 | 4.5 | 1.2 | 0.09 | 0.16 | 0.25 |
|
SC16-110SW0A
|
1.10 | 2.20 | 16 | 40 | 0.70 | 3.30 | 10 | 0.07 | 0.14 | 0.21 |
|
|
SC16-120CW0A
|
1.20 | 2.40 | 16 | 40 | 0.75 | 3.6 | 10 | 0.7 | 0.14 | 0.21 |
|
|
SC16-135SW0A
|
1.35 | 2.70 | 16 | 40 | 0.80 | 4.05 | 10 | 0.055 | 0.11 | 0.14 |
|
|
SC16-160SW0A
|
1.60 | 3.20 | 16 | 40 | 0.90 | 4.80 | 10 | 0.045 | 0.09 | 0.115 |
|
|
SC16-185SW0A
|
1.85 | 3.70 | 16 | 40 | 1.0 | 5.55 | 12 | 0.04 | 0.08 | 0.1 |
|
|
SC16-250CW0A
|
2.50 | 5.0 | 16 | 40 | 1.2 | 7.5 | 12 | 0.027 | 0.055 | 0.07 |
|
|
SC16-300CW0A
|
3.0 | 5.0 | 16 | 100 | 2.3 | 9.0 | 7.0 | 0.027 | 0.0645 | 0.0975 |
|
|
SC16-300SZ0D
|
3.00 | 6.0 | 16 | 40 | 2.30 | 15.0 | 2.0 | 0.038 | 0.070 | 0.110 |
|
|
SC16-400SZ0A
|
4.0 | 6.8 | 16 | 100 | 2.4 | 12 | 7.0 | 0.02 | 0.044 | 0.06 |
|
|
SC16-400SZ0D
|
4.00 | 8.0 | 16 | 40 | 2.4 | 20 | 3.5 | 0.021 | 0.04 | 0.08 |
|
|
SC16-500SZ0A
|
5.0 | 8.5 | 16 | 100 | 2.6 | 15 | 10 | 0.014 | 0.028 | 0.034 |
|
|
SC16-500SZ0D
|
5.00 | 10.00 | 16 | 40 | 2.60 | 25.0 | 3.6 | 0.015 | 0.025 | 0.040 |
|
|
SC16-600SZ0A
|
6.0 | 10.2 | 16 | 100 | 2.8 | 18 | 10 | 0.01 | 0.022 | 0.028 |
|
|
SC16-600SZ0D
|
6.00 | 12.00 | 16 | 40 | 2.80 | 30.0 | 5.8 | 0.010 | 0.020 | 0.035 |
|
|
SC16-700SZ0D
|
7.00 | 14.0 | 16 | 40 | 3.0 | 35.0 | 8 | 0.008 | 0.015 | 0.022 |
|
|
SC16-800SZ0D
|
8.00 | 16.00 | 16 | 40 | 3.00 | 40.0 | 9.0 | 0.006 | 0.012 | 0.021 |
|
SC16-1000SZ0D
|
10.00 | 20.00 | 16 | 40 | 3.6 | 50.0 | 12.5 | 0.004 | -- | 0.013 |
|
|
SC16-1400SZ0D
|
14.00 | 28.00 | 16 | 40 | 4.60 | 70.0 | 20.0 | 0.003 | 0.005 | 0.008 |
|
